Pay Your Way, 8000+ Cycles, Reliable Power Lighting Up Lives.

Features 8,000-cycle lifespan, flexible Pay-Go payment, and all-in-one ports for enduring, worry-free power anywhere.

LFP 314Ah

Large Capacity Battery Cells

8000+

Cycles

Advantages

8,000+ Cycles

High-grade LFP 314Ah cells deliver exceptional longevity with over 8,000 cycles .

3-in-1 Integration

PCS+BMS+DC/DC all-in-one design enhances reliability and reduces failure risk.

2 Mounting Options

Flexible floor or wall mounting adapts to various usage scenarios.

11 Output Ports

2AC+4USB+1Type-C+4DC ports support multiple devices simultaneously.

Pay-As-You-Go

Built-in flexible payment option reduces purchase barriers through installments.

Plug-and-play

Compact design for easy operation.

Parameters

ESS SERIES

All-in-one ESS

ESS-2000

Rated Capacity

1000 W / 2009 Wh

Maximum Input Power

550 W

Max. Input Voltage

60 Vdc

MPPT Range @Operating Voltage

12 ~ 55 Vdc

Max. Input Current

15 A

Max. Short-circuit Current

20 A

Rated Voltage

6.4 V

Cell Type

Lithium-LFP

Rated Capacity

2009 Wh

Cycle Life

> 8000 Cycles

Rated Voltage

208 / 220 / 230 / 240 Vac; L + N + PE

Voltage Range

90 ~ 280 Vac ± 5 Vac (normal mode)

Frequency

50 / 60 Hz ± 5 Hz

Max. Input Power

1500W (Including Bypass, AC charge Max. 1000W)

Ingress Protection

IP21

Operating Temperature

-10 ℃ ~ 50 ℃ (When charging, temperature must not be below 0°C)

Dimensions (D * W * H)

160 * 400 * 250 mm

Net Weight

18.7 kg

Humidity

5% ~ 95% (Non-condensing)

Protection

AC input/output UVP/OVP, Battery UVP/OVP, AC Output OLP/SCP, OTP
