EV Charger Modular PCS SI3P
Hi Series Three Phase
Hybrid Inverter
8kW | 10kW | 12kW | 15kW
Efficient and Reliable Hybrid Inverter Solution.

YINERGY Hybrid Inverter supports 200% PV oversizing and 110% AC overload, with <4ms seamless switchover to power high-demand appliances effortlessly. This high-performance system ensures efficient and stable energy conversion, delivering reliable protection for critical loads and sensitive devices.

IP65
Protection Degree
＜ 4ms
Single Unit UPS-level Switchover Time
Advantages
290A
Max. charging / discharging current
200%
PV oversizing
160V
Low start-up voltage
Parameters
Hi Series Three Phase
Hybrid Inverter
HI-3P15K-LV
HI-3P15K-LV
HI-3P12K-LV
HI-3P10K-LV
HI-3P8K-LV
Max. PV Array Power
30000 W
Max. PV Input Power
24000 W
Max. PV Input Voltage
800 V
Rated Voltage
550 V
Start-up Voltage
160 V
MPPT Range
200~700 V
Battery Type
Lead acid or Lithium
Rated Voltage
48 V
Voltage Range
40~60 V
Max.Current
290 A
Rated Output Power
15000 W
Max. Output Power
16500 VA
Max. input Power
16500 VA
Peak Efficiency
97.6%
MPPT Eficiency
99%
Communication Interface
RS485/RS232/CAN
Type of Cooling
Intelligent Air Cooling
Size(LxHxD)
422 x 658 x 254 mm
Weight
45 kg
Operating Temperature Range
-25℃ ~ +60℃
Ingress protection
IP65
Max. PV Array Power
24000 W
Max. PV Input Power
19200 W
Max. Pv Input Voltage
800 V
Rated Voltage
550 V
Start-up Voltage
160 V
MPPT Range
200~700 V
Battery Type
Lead-acid or Lithium-ion
Rated Voltage
48
Voltage Range
40~60 V
Max.curent
250 A
Rated Output Power
12000 W
Max. output Power
13200 VA
Max. input Power
13200 VA
Peak Efficiency
97.6%
MPPT Eficiency
99%
Communication Interace
RS485 / RS232 / CAN
Type of Cooling
Intelligent Air Cooling
Size(LxHxD)
422 × 658 × 254 mm
Weight
45 kg
Operating Temperature Range
-25 ℃~ +60 ℃
Ingress protection
IP65
Max. PV Array Power
2000 W
Max. PV input Power
16000 W
Max. PV Input Voltage
800 V
Rated Voltage
550 V
Start-up Voltage
160 V
MPPT Range
200~700 V
Battery Type
Lead-acid or Lithium-ion
Rated Voltage
48 V
Voltage Range
40~60 V
Max.curent
220 A
Rated Output Power
10000 W
Max. output Power
11000 VA
Max. input Power
11000 VA
Peak Efficiency
97.6%
MPPT Eficiency
99%
Communication Interace
RS485 / RS232 / CAN
Type of Cooling
Intelligent Air Cooling
Size(LxHxD)
422 × 658 × 254 mm
Operating Temperature Range
-25 ℃~ +60 ℃
Ingress protection
IP65
Max. PV Array Power
16000 W
Max. PV Input Power
12800 W
Max. PV Input Voltage
800 V
Rated Voltage
550 V
Start-up Voltage
160 V
MPPT Range
200 - 700 V
Battery Type
Lead-acid or Lithium-ion
Rated Voltage
48 V
Voltage Range
40~60 V
Max.curent
200 A
Rated Output Power
8000 W
Max. output Power
8800 VA
Max. input Power
8800 VA
Peak Efficiency
97.60%
MPPT Eficiency
99%
Communication Interace
RS485 / RS232 / CAN
Type of Cooling
Intelligent Air Cooling
Size(LxHxD)
422 × 658 × 254 mm
Weight
45 kg
Operating Temperature Range
-25 ℃~ +60 ℃
Ingress protection
IP65
